Volume pricing
- 1+ pcs$0.65
- 10+ pcs$0.61
- 100+ pcs$0.58
- 500+ pcs$0.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Through Hole
- Orientation
- Straight
- Parça Durumu
- Active
- Contact Lengthmating
- 0.230 5.84mm
- Din Conformance
- NO
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Contact Length Post
- 0.120 3.05mm
- Mating Contact Pitch
- 0.05 inch
- Filter Feature
- NO
- Insulation Height
- 0.100 2.54mm
- Contact Finish Mating
- Gold
- Fastening Type
- Push-Pull
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 3.81mm
- Fabrika Tedarik Süresi
- 3 Weeks
- Housing Material
- Polymer
- Insulation Color
- Black
- Number Of Pcb Rows
- 1
- Sıra Sayısı
- 1
- Contact Materials
- Phosphor Bronze
- Mixed Contacts
- NO
- Reach Svhc
- No SVHC
- Iec Conformance
- NO
- Contact Type
- Male Pin
- Style
- Board to Board
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Yayın Yılı
- 2012
- Option
- GENERAL PURPOSE
- Max Current Rating
- 1A
- Connector Type
- Header
- Depth
- 2.48mm
- Current Rating Amps
- 5A per Contact
- Material Flammability Rating
- UL94 V-0
- Number Of Positions Loaded
- All
- Number Of Conductors
- ONE
- Çalışma Sıcaklığı
- -55°C~125°C
- Reference Standard
- UL
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Gender
- Male
- Contact Shape
- Square
