Volume pricing
- 1+ pcs$1.35
- 10+ pcs$1.28
- 100+ pcs$1.20
- 500+ pcs$1.14
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 3 Weeks
- Contact Lengthmating
- 0.126 3.20mm
- ECCN Kodu
- EAR99
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Özellikler
- Pick and Place
- Gender
- Male
- Kurşunsuz
- Lead Free
- HTS Kodu
- 8536.69.40.40
- Contact Shape
- Square
- Max Current Rating
- 3.9A
- Shrouding
- Unshrouded
- Number Of Positions Loaded
- All
- Voltage Rated Ac
- 250V
- Montaj Tipi
- Surface Mount
- Insulation Height
- 0.059 1.50mm
- Fastening Type
- Push-Pull
- Style
- Board to Board or Cable
- Connector Type
- Header
- Material Flammability Rating
- UL94 V-0
- Uzunluk
- 14mm
- Row Spacing Mating
- 0.079 (2.00mm)
- Sıra Sayısı
- 2
- Housing Color
- Black
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- Max Voltage Rating Ac
- 500V
- Orientation
- Straight
- Yayın Yılı
- 2008
- Contact Materials
- Phosphor Bronze
- Seri
- TMM
- Housing Material
- Polymer
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e3
- Ambalaj
- Tape & Reel (TR)
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~105°C
- Depth
- 3.94mm
- RoHS Durumu
- ROHS3 Compliant
- Current Rating Amps
- 3.2A per Contact
- Terminal
- Solder
