Volume pricing
- 1+ pcs$1.44
- 10+ pcs$1.36
- 100+ pcs$1.28
- 500+ pcs$1.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 3.2A per Contact
- Number Of Conductors
- ONE
- Ambalaj
- Bulk
- Housing Material
- Polymer
- Seri
- TMM
- Mil Conformance
- NO
- Orientation
- Straight
- Iec Conformance
- NO
- Pozisyon Sayısı
- 10
- Mating Contact Pitch
- 0.079 inch
- Contact Type
- Male Pin
- Option
- GENERAL PURPOSE
- Pitch Mating
- 0.079 2.00mm
- Radyasyon Dayanımı
- No
- Reliability
- COMMERCIAL
- Terminal
- Solder
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Contact Length Post
- 0.138 3.50mm
- Shrouding
- Unshrouded
- Max Current Rating
- 3.9A
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 3.94mm
- Gender
- Male
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Lengthmating
- 0.126 3.20mm
- Plating Thickness
- 30μin
- Number Of Pcb Rows
- 2
- Parça Durumu
- Active
- Sıra Sayısı
- 2
- Housing Color
- Black
- Connector Type
- Header
- Style
- Board to Board or Cable
- Insulation Height
- 0.059 1.50mm
- Montaj Tipi
- Through Hole
- Pcb Contact Pattern
- RECTANGULAR
- Number Of Positions Loaded
- All
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 3.94mm
