Volume pricing
- 1+ pcs$8.23
- 10+ pcs$7.77
- 100+ pcs$7.33
- 500+ pcs$6.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Shrouding
- Shrouded - 4 Wall
- Din Conformance
- NO
- Kurşunsuz Kodu
- yes
- Housing Color
- Black
- Style
- Board to Board or Cable
- Contact Lengthmating
- 0.134 3.39mm
- Option
- GENERAL PURPOSE
- RoHS Durumu
- ROHS3 Compliant
- Rated Current Signal
- 5A
- Plating Thickness
- 30μin
- Contact Length Post
- 0.075 1.91mm
- Reliability
- COMMERCIAL
- Yayın Yılı
- 2005
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Contact Finish Mating
- Gold
- Akım Değeri
- 5A
- Voltage Rated Ac
- 350V
- Contact Shape
- Square
- Row Spacing Mating
- 0.050 (1.27mm)
- Pcb Contact Pattern
- RECTANGULAR
- Housing Material
- Plastic
- Gender
- Male
- Number Of Pcb Rows
- 2
- Montaj Tipi
- Through Hole
- Ambalaj
- Tube
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Montaj
- Through Hole
- Number Of Positions Loaded
- All
- Reference Standard
- UL, CSA
- Seri
- Tiger Eye™ TFML
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Mixed Contacts
- NO
- Pozisyon Sayısı
- 80
- Sıra Sayısı
- 2
- Radyasyon Dayanımı
- No
- Material Flammability Rating
- UL94 V-0
