Volume pricing
- 1+ pcs$3.69
- 10+ pcs$3.48
- 100+ pcs$3.28
- 500+ pcs$3.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal
- Solder
- Contact Materials
- Phosphor Bronze
- Additional Feature
- ELP; TIGER EYE, SHROUDED
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.134 3.39mm
- Style
- Board to Board or Cable
- Housing Color
- Black
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 5A
- Option
- GENERAL PURPOSE
- Depth
- 5.72mm
- Yayın Yılı
- 2006
- Reliability
- COMMERCIAL
- Plating Thickness
- 30μin
- Row Spacing Mating
- 0.050 (1.27mm)
- Uzunluk
- 15.88mm
- Voltage Rated Ac
- 350V
- Contact Shape
- Square
- Akım Değeri
- 5A
- Contact Finish Mating
- Gold
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Gender
- Male
- Montaj Tipi
- Surface Mount
- Ambalaj
- Tube
- Number Of Pcb Rows
- 2
- Number Of Positions Loaded
- All
- Montaj
- Surface Mount
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Mixed Contacts
- NO
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Seri
- Tiger Eye™ TFML
- Reference Standard
- UL, CSA
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 2
