Volume pricing
- 1+ pcs$3.68
- 10+ pcs$3.47
- 100+ pcs$3.28
- 500+ pcs$3.09
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Male
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Post
- Tin
- Contact Type
- Male Pin
- Contact Finish Mating
- Gold
- Contact Shape
- Square
- Voltage Rated Ac
- 350V
- Akım Değeri
- 5A
- Row Spacing Mating
- 0.050 (1.27mm)
- Uzunluk
- 15.88mm
- Plating Thickness
- 30μin
- Rated Current Signal
- 5A
- Reliability
- COMMERCIAL
- Contact Length Post
- 0.075 1.91mm
- Yayın Yılı
- 2008
- Depth
- 7.37mm
- Max Current Rating
- 5A
- Option
- GENERAL PURPOSE
- RoHS Durumu
- ROHS3 Compliant
- Style
- Board to Board or Cable
- Contact Lengthmating
- 0.134 3.39mm
- Housing Color
- Black
- Kurşunsuz Kodu
- yes
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Additional Feature
- ROHS COMPLIANT
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 3 Weeks
- Polarization Key
- POLARIZED HOUSING
- Reach Svhc
- No SVHC
- Mating Contact Pitch
- 0.05 inch
- Iec Conformance
- NO
- JESD-609 Kodu
- e3
- Fastening Type
- Friction Lock
- Orientation
- Right Angle
- Pitch Mating
- 0.050 1.27mm
- Nominal Gerilim
- 350V
- Insulation Height
- 0.225 5.72mm
