Volume pricing
- 1+ pcs$7.84
- 10+ pcs$7.40
- 100+ pcs$6.98
- 500+ pcs$6.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal
- Solder
- Insulation Color
- Black
- Contact Materials
- Phosphor Bronze
- Additional Feature
- WITH WELD TAB, ROHS COMPLIANT
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.139 3.53mm
- Current Rating Amps
- 2.9A per Contact
- Style
- Board to Board or Cable
- Option
- GENERAL PURPOSE
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2011
- Body Length Or Diameter
- 1.763 inch
- Plating Thickness
- 30μin
- Reliability
- COMMERCIAL
- Contact Length Post
- 0.078 1.98mm
- Contact Shape
- Square
- Body Depth
- 0.315 inch
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Finish Post
- Tin
- Contact Type
- Male Pin
- Contact Finish Mating
- Gold
- Pcb Contact Pattern
- RECTANGULAR
- Gender
- Male
- Montaj Tipi
- Through Hole, Right Angle
- Ambalaj
- Tube
- Number Of Pcb Rows
- 2
- Ul Flammability Code
- 94V-0
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Montaj
- Through Hole
- Number Of Positions Loaded
- All
- Parça Durumu
- Active
- Seri
- Tiger Eye™ TFM
- Mixed Contacts
- NO
- Reference Standard
- UL, CSA
- Material Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 60
- Sıra Sayısı
- 2
- Connector Type
- Header, Elevated
- Number Of Conductors
- ONE
