Volume pricing
- 1+ pcs$7.99
- 10+ pcs$7.54
- 100+ pcs$7.11
- 500+ pcs$6.71
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Pcb Rows
- 2
- Montaj Tipi
- Surface Mount
- Ambalaj
- Tube
- Number Of Positions Loaded
- All
- Ul Flammability Code
- 94V-0
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Reference Standard
- UL, CSA
- Mixed Contacts
- NO
- Parça Durumu
- Active
- Seri
- Tiger Eye™ TFM
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 50
- Material Flammability Rating
- UL94 V-0
- Max Voltage Rating Ac
- 350V
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Çalışma Sıcaklığı
- -55°C~125°C
- Mil Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Conductors
- ONE
- Connector Type
- Header
- Total Number Of Contacts
- 50
- Fastening Type
- Push-Pull
- Özellikler
- Board Lock
- Orientation
- Straight
- Iec Conformance
- NO
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.050 1.27mm
- Nominal Gerilim
- 275VAC
- Insulation Height
- 0.435 11.05mm
- Filter Feature
- NO
- Mating Contact Pitch
- 0.05 inch
- Fabrika Tedarik Süresi
- 3 Weeks
- Reach Svhc
- No SVHC
- Polarization Key
- POLARIZED HOUSING
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Insulation Color
- Black
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Additional Feature
- NONE
