Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Male
- Fabrika Tedarik Süresi
- 3 Weeks
- Connector Type
- Header
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Çalışma Sıcaklığı
- -55°C~125°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Height
- 0.220 5.60mm
- Nominal Gerilim
- 275VAC
- Pitch Mating
- 0.050 1.27mm
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Shape
- Square
- Contact Finish Mating
- Gold
- Fastening Type
- Push-Pull
- Özellikler
- Pick and Place, Solder Retention
- Contact Type
- Male Pin
- JESD-609 Kodu
- e3
- Contact Finish Post
- Tin
- Kurşunsuz Kodu
- yes
- Contact Lengthmating
- 0.131 3.33mm
- Current Rating Amps
- 2.9A per Contact
- Style
- Board to Board or Cable
- Seri
- Tiger Eye™ TFM
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- ROHS3 Compliant
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 40
- Ambalaj
- Tape & Reel (TR)
- Montaj Tipi
- Surface Mount
- Terminal
- Solder
- Insulation Color
- Black
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- All
- Shrouding
- Shrouded - 4 Wall
- Insulation Materials
- Liquid Crystal Polymer (LCP)
