Volume pricing
- 1+ pcs$1.86
- 10+ pcs$1.75
- 100+ pcs$1.65
- 500+ pcs$1.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Male
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Contact Shape
- Square
- Row Spacing Mating
- 0.050 (1.27mm)
- Uzunluk
- 9.53mm
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Contact Finish Mating
- Gold
- Yayın Yılı
- 2011
- Plating Thickness
- 30μin
- Reliability
- COMMERCIAL
- Contact Length Post
- 0.080 2.03mm
- Max Current Rating
- 5A
- Option
- GENERAL PURPOSE
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 5.72mm
- Mounting Option1
- GUIDE SLOT
- Style
- Board to Board or Cable
- Current Rating Amps
- 2.9A per Contact
- Contact Lengthmating
- 0.139 3.53mm
- Kurşunsuz Kodu
- yes
- Additional Feature
- E.L.P.
- Din Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- HTS Kodu
- 8536.69.40.40
- Terminal
- Solder
- Insulation Color
- Black
- Contact Materials
- Phosphor Bronze
- Polarization Key
- POLARIZED HOUSING
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 3 Weeks
- Mating Contact Pitch
- 0.05 inch
- Nominal Gerilim
- 275VAC
- Pitch Mating
- 0.050 1.27mm
- Filter Feature
- NO
- Insulation Height
- 0.290 7.37mm
- Iec Conformance
- NO
- JESD-609 Kodu
- e3
- Fastening Type
- Push-Pull
