Specifications
- Iec Conformance
- NO
- JESD-609 Kodu
- e3
- Mounting Option1
- LOCKING
- Max Current Rating
- 3A
- Fastening Type
- Push-Pull
- Contact Shape
- Square
- Özellikler
- Solder Retention
- Pitch Mating
- 0.079 2.00mm
- Seri
- Tiger Eye™ T2M
- Yayın Yılı
- 2013
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 3.8A
- Filter Feature
- NO
- Mating Contact Pitch
- 0.079 inch
- Style
- Board to Board or Cable
- Plating Thickness
- 10μin
- Number Of Positions Loaded
- All
- Insulation Height
- 0.293 7.44mm
- Contact Materials
- Phosphor Bronze
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 2
- Mil Conformance
- NO
- Montaj Tipi
- Through Hole, Right Angle
- Mixed Contacts
- NO
- Sıra Sayısı
- 2
- Uzunluk
- 25.67mm
- Number Of Conductors
- ONE
- Shrouding
- Shrouded - 4 Wall
- Depth
- 9.31mm
- Contact Finish Post
- Tin
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Male
- Contact Length Post
- 0.090 2.29mm
- Orientation
- Right Angle
- Contact Type
- Male Pin
- Insulation Color
- Black
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~125°C
- Pozisyon Sayısı
- 20
- Fabrika Tedarik Süresi
- 5 Weeks
