Volume pricing
- 1+ pcs$6.04
- 10+ pcs$5.70
- 100+ pcs$5.37
- 500+ pcs$5.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 3 Weeks
- Gender
- Male
- Housing Material
- Nylon
- Contact Type
- Male Pin
- JESD-609 Kodu
- e3
- Contact Finish Post
- Tin
- Iec Conformance
- NO
- Orientation
- Straight
- Contact Finish Mating
- Gold
- Fastening Type
- Push-Pull
- Özellikler
- Keying Slot
- Contact Shape
- Square
- Insulation Height
- 0.190 4.83mm
- Uzunluk
- 16.17mm
- Row Spacing Mating
- 0.079 (2.00mm)
- Pitch Mating
- 0.079 2.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mil Conformance
- NO
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Çalışma Sıcaklığı
- -55°C~125°C
- Connector Type
- Header
- Yayın Yılı
- 2012
- Pozisyon Sayısı
- 10
- Depth
- 6.51mm
- Sıra Sayısı
- 2
- Option
- GENERAL PURPOSE
- Radyasyon Dayanımı
- No
- RoHS Durumu
- ROHS3 Compliant
- Seri
- Flex Stack, STMM
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Contact Lengthmating
- 0.120 3.05mm
- Current Rating Amps
- 3A
- Style
- Board to Cable/Wire
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Shrouding
- Shrouded - 4 Wall
- Din Conformance
- NO
- Number Of Positions Loaded
- All
- Contact Materials
- Phosphor Bronze
- Montaj Tipi
- Surface Mount
