SSW-105-02-G-D-RA

Specifications

Connector Type

Receptacle

Mixed Contacts

NO

Mating Contact Pitch

0.1 inch

Ul Flammability Code

94V-0

Radyasyon Dayanımı

No

Fastening Type

Push-Pull

Row Spacing Mating

0.100 (2.54mm)

Contact Shape

Square

Number Of Positions Loaded

All

Contact Length Post

0.100 2.54mm

Terminal

Solder

Insulation Materials

Liquid Crystal Polymer (LCP)

RoHS Durumu

ROHS3 Compliant

Mil Conformance

NO

Max Current Rating

6.9A

Additional Feature

TIGER BUY CONTACT

Material Flammability Rating

UL94 V-0

Contact Finish Thickness Mating

20.0μin 0.51μm

Ambalaj

Bulk

JESD-609 Kodu

e4

Montaj Tipi

Through Hole, Right Angle

Akım Değeri

6.9A

Seri

SSW

Reach Svhc

No SVHC

Max Voltage Rating Ac

550V

Yayın Yılı

2000

Din Conformance

NO

Reliability

COMMERCIAL

Option

GENERAL PURPOSE

Pitch Mating

0.100 2.54mm

Pcb Contact Pattern

RECTANGULAR

Contact Gender

FEMALE

Depth

12.57mm

Filter Feature

NO

Body Breadth

0.195 inch

Contact Type

Forked

Housing Material

Polymer

Kurşunsuz Kodu

yes

Voltage Rated Ac

465V

Lead Pitch

2.54mm
