Volume pricing
- 1+ pcs$1.06
- 10+ pcs$1.00
- 100+ pcs$0.94
- 500+ pcs$0.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Terminal
- Solder
- RoHS Durumu
- ROHS3 Compliant
- Mil Conformance
- NO
- Max Current Rating
- 6.9A
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Additional Feature
- TIGER BUY CONTACT
- JESD-609 Kodu
- e3
- Montaj Tipi
- Through Hole
- Reach Svhc
- No SVHC
- Seri
- SSW
- Din Conformance
- NO
- Max Voltage Rating Ac
- 550V
- Yayın Yılı
- 2000
- Reliability
- COMMERCIAL
- Connector Type
- Receptacle
- Mixed Contacts
- NO
- Mating Contact Pitch
- 0.1 inch
- Row Spacing Mating
- 0.100 (2.54mm)
- Fastening Type
- Push-Pull
- Radyasyon Dayanımı
- No
- Ul Flammability Code
- 94V-0
- Contact Shape
- Square
- Number Of Positions Loaded
- All
- Contact Length Post
- 0.104 2.64mm
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 1 Weeks
- Insulation Height
- 0.335 8.51mm
- Contact Materials
- Phosphor Bronze
- Nem Hassasiyeti (MSL)
- Not Applicable
- Contact Finish Mating
- Tin
- Genişlik
- 4.95mm
- Number Of Conductors
- ONE
- Current Rating Amps
- 5.7A per Contact
- Montaj
- Through Hole
- Sıra Sayısı
- 2
- Style
- Board to Board or Cable
- Contact Resistance
- 10mOhm
- Pozisyon Sayısı
- 10
