Volume pricing
- 1+ pcs$1.17
- 10+ pcs$1.10
- 100+ pcs$1.04
- 500+ pcs$0.98
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mounting Option1
- LOCKING
- Depth
- 4.95mm
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 6.9A
- Option
- GENERAL PURPOSE
- Current Rating Amps
- 5.7A per Contact
- Style
- Board to Board or Cable
- Contact Resistance
- 10mOhm
- Housing Color
- Black
- Kurşunsuz Kodu
- yes
- Lead Length
- 2.64mm
- Din Conformance
- NO
- Additional Feature
- TIGER BUY CONTACT
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Mating
- Gold
- Contact Finish Post
- Tin
- Contact Type
- Forked
- Row Spacing Mating
- 0.100 (2.54mm)
- Uzunluk
- 10.67mm
- Voltage Rated Ac
- 465V
- Contact Shape
- Square
- Reliability
- COMMERCIAL
- Contact Length Post
- 0.104 2.64mm
- Plating Thickness
- 3μin
- Voltage Rated Dc
- 655V
- Yayın Yılı
- 2013
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 8
- Material Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- Reference Standard
- UL
- Lead Pitch
- 2.54mm
- Mixed Contacts
- NO
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Seri
- SSW
- Number Of Positions Loaded
- All
