Volume pricing
- 1+ pcs$1.19
- 10+ pcs$1.12
- 100+ pcs$1.06
- 500+ pcs$1.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Row Spacing Mating
- 0.100 (2.54mm)
- Uzunluk
- 5.59mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Shape
- Square
- Voltage Rated Ac
- 465V
- Akım Değeri
- 6.9A
- Contact Finish Mating
- Gold
- Contact Type
- Forked
- Voltage Rated Dc
- 655V
- Yayın Yılı
- 2000
- Reliability
- COMMERCIAL
- Contact Length Post
- 0.104 2.64mm
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Additional Feature
- TIGER BUY CONTACT
- Din Conformance
- NO
- Terminal
- Solder
- Contact Materials
- Phosphor Bronze
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 5.5A
- Option
- GENERAL PURPOSE
- Depth
- 4.95mm
- Style
- Board to Board or Cable
- Contact Resistance
- 10mOhm
- Current Rating Amps
- 5.7A per Contact
- Kurşunsuz Kodu
- yes
- Housing Color
- Black
- Lead Length
- 2.64mm
- Pitch Mating
- 0.100 2.54mm
- Insulation Height
- 0.335 8.51mm
- Body Breadth
- 0.195 inch
- Filter Feature
- NO
- Fastening Type
- Push-Pull
- Orientation
- Straight
- Iec Conformance
- NO
- JESD-609 Kodu
- e4
- Number Of Conductors
- ONE
- Connector Type
- Receptacle
- Max Voltage Rating Ac
- 550V
- Contact Finish Thickness Mating
- 20.0μin 0.51μm
