Volume pricing
- 1+ pcs$27.84
- 10+ pcs$26.26
- 100+ pcs$24.77
- 500+ pcs$23.37
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mating Contact Pitch
- 0.1 inch
- Çalışma Sıcaklığı
- -55°C~125°C
- Filter Feature
- NO
- Pitch Mating
- 0.100 2.54mm
- Din Conformance
- NO
- Insertion Forcemax
- 1.668 N
- Yükseklik
- 4.95mm
- Genişlik
- 8.51mm
- Montaj Tipi
- Through Hole, Right Angle
- Parça Durumu
- Discontinued
- Contact Type
- Forked
- Style
- Board to Board or Cable
- Kurşunsuz Kodu
- yes
- Connector Type
- Receptacle
- Insulation Height
- 0.195 4.95mm
- Seri
- SSQ
- Plating Thickness
- 30μin
- Fastening Type
- Push-Pull
- Withdrawl Forcemin
- 1.39 N
- Number Of Pcb Rows
- 2
- Mixed Contacts
- NO
- Contact Shape
- Square
- HTS Kodu
- 8536.69.40.40
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Housing Material
- Plastic
- Mil Conformance
- NO
- Number Of Conductors
- ONE
- Nominal Gerilim
- 550VAC
- Contact Length Post
- 0.100 2.54mm
- Additional Feature
- TIGER BUY CONTACT
- Yayın Yılı
- 2011
- Housing Color
- Black
- Radyasyon Dayanımı
- No
- JESD-609 Kodu
- e3
- Contact Finish Mating
- Gold
- Material Flammability Rating
- UL94 V-0
- Current Rating Amps
- 6.3A per Contact
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Post
- Tin
- Body Depth
- 0.335 inch
