Volume pricing
- 1+ pcs$7.76
- 10+ pcs$7.32
- 100+ pcs$6.90
- 500+ pcs$6.51
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Ac
- 465V
- JESD-609 Kodu
- e4
- Insulation Color
- Black
- Voltage Rated Dc
- 655V
- Row Spacing Mating
- 0.100 (2.54mm)
- Body Depth
- 0.335 inch
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Mating
- Gold
- Fabrika Tedarik Süresi
- 3 Weeks
- Material Flammability Rating
- UL94 V-0
- Current Rating Amps
- 6.3A per Contact
- Pozisyon Sayısı
- 52
- Contact Resistance
- 10mOhm
- Option
- GENERAL PURPOSE
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Kurşunsuz
- Lead Free
- Reference Standard
- UL, CSA
- Body Breadth
- 0.195 inch
- Sıra Sayısı
- 2
- Terminal
- Solder
- Contact Finish Thickness Mating
- 20.0μin 0.51μm
- Iec Conformance
- NO
- Gender
- Female
- Reliability
- COMMERCIAL
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Ambalaj
- Bulk
- Number Of Positions Loaded
- All
- Lead Length
- 2.64mm
- Din Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Çalışma Sıcaklığı
- -55°C~125°C
- Mating Contact Pitch
- 0.1 inch
- Pitch Mating
- 0.100 2.54mm
- Filter Feature
- NO
- Insulation Height
- 0.335 8.51mm
- Connector Type
- Receptacle
- Seri
- SSQ
