Volume pricing
- 1+ pcs$3.10
- 10+ pcs$2.93
- 100+ pcs$2.76
- 500+ pcs$2.61
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reliability
- COMMERCIAL
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Ambalaj
- Bulk
- Number Of Positions Loaded
- All
- Iec Conformance
- NO
- Gender
- Female
- Kurşunsuz
- Lead Free
- Reference Standard
- UL, CSA
- Terminal
- Solder
- Sıra Sayısı
- 2
- Body Breadth
- 0.195 inch
- Contact Finish Thickness Mating
- 20.0μin 0.51μm
- Pozisyon Sayısı
- 20
- Contact Resistance
- 10mOhm
- Option
- GENERAL PURPOSE
- ECCN Kodu
- EAR99
- Pcb Contact Pattern
- RECTANGULAR
- Fabrika Tedarik Süresi
- 3 Weeks
- Contact Finish Mating
- Gold
- Current Rating Amps
- 6.3A per Contact
- Material Flammability Rating
- UL94 V-0
- Max Voltage Rating Ac
- 550V
- Row Spacing Mating
- 0.100 (2.54mm)
- Uzunluk
- 25.91mm
- Depth
- 4.95mm
- Insulation Color
- Black
- Voltage Rated Dc
- 655V
- Radyasyon Dayanımı
- No
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Ac
- 465V
- JESD-609 Kodu
- e4
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Additional Feature
- TIGER BUY CONTACT
- Contact Length Post
- 0.584 14.83mm
- Number Of Pcb Rows
- 2
- Fastening Type
- Push-Pull
- Max Current Rating
- 7.6A
- Housing Material
- Polymer
- Insulation Materials
- Liquid Crystal Polymer (LCP)
