Volume pricing
- 1+ pcs$2.02
- 10+ pcs$1.90
- 100+ pcs$1.80
- 500+ pcs$1.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Conductors
- ONE
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Iec Conformance
- NO
- Yayın Yılı
- 2003
- ECCN Kodu
- EAR99
- Yükseklik
- 5.46mm
- Insertion Forcemax
- 2.78 N
- Parça Durumu
- Active
- Contact Length Post
- 0.656 16.66mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Type
- Female Socket
- Housing Material
- Plastic
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- All
- Style
- Board to Board
- Montaj
- Through Hole
- Contact Finish Mating
- Tin
- Mixed Contacts
- NO
- Fastening Type
- Push-Pull
- Flammability Rating
- UL94 V-0
- Terminal
- Wire Wrap
- Insulation Resistance
- 5000000000Ohm
- Insulation Height
- 0.230 5.85mm
- Nominal Gerilim
- 1000V
- Montaj Tipi
- Through Hole
- Mil Conformance
- NO
- Seri
- SSA
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Receptacle, Breakaway
- Number Of Pcb Rows
- 1
- JESD-609 Kodu
- e3
- Din Conformance
- NO
- Kurşunsuz Kodu
- yes
- Pitch Mating
- 0.100 2.54mm
- Uzunluk
- 33mm
- Material Flammability Rating
- UL94 V-0
- Contact Shape
- Square
- Housing Color
- Black
