Volume pricing
- 1+ pcs$0.97
- 10+ pcs$0.92
- 100+ pcs$0.87
- 500+ pcs$0.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Receptacle, Breakaway
- Number Of Pcb Rows
- 1
- JESD-609 Kodu
- e3
- Din Conformance
- NO
- Montaj Tipi
- Through Hole
- Mil Conformance
- NO
- Seri
- SSA
- Insulation Resistance
- 5000000000Ohm
- Insulation Height
- 0.230 5.85mm
- Nominal Gerilim
- 1000V
- Terminal
- Solder
- Fastening Type
- Push-Pull
- Orientation
- Straight
- Flammability Rating
- UL94 V-0
- Contact Finish Mating
- Tin
- Montaj
- Through Hole
- Max Voltage Rating Ac
- 1kV
- Mixed Contacts
- NO
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- All
- Style
- Board to Board
- Parça Durumu
- Active
- Contact Length Post
- 0.151 3.84mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Type
- Female Socket
- Housing Material
- Polyethylene
- Depth
- 2.54mm
- Insertion Forcemax
- 2.78 N
- Max Current Rating
- 1A
- Iec Conformance
- NO
- Yayın Yılı
- 2003
- Number Of Conductors
- ONE
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Reliability
- COMMERCIAL
- Genişlik
- 2.54mm
- Reference Standard
- UL
- Ambalaj
- Bulk
