SQT-130-03-F-D

Specifications

Body Breadth

0.158 inch

Option

GENERAL PURPOSE

Contact Shape

Square

Voltage Rated Ac

450V

Sıra Sayısı

2

Insulation Color

Black

Withdrawl Forcemin

.834 N

Pitch Mating

0.079 2.00mm

Material Flammability Rating

UL94 V-0

Contact Finish Thickness Mating

Flash

Row Spacing Mating

0.079 (2.00mm)

Current Rating Amps

5.1A per Contact

Reliability

COMMERCIAL

Reference Standard

UL, CSA

Lead Length

6.28mm

Pozisyon Sayısı

60

Filter Feature

NO

Contact Resistance

10mOhm

Insulation Materials

Liquid Crystal Polymer (LCP)

Ambalaj

Tube

Durability

100 Cycles

Gender

Female

Additional Feature

FLEXYZ, TIGER BUY CONTACT

Çalışma Sıcaklığı

-55°C~125°C

Contact Length Post

0.208 5.28mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Type

Forked

Parça Durumu

Active

Mating Contact Pitch

0.079 inch

Iec Conformance

NO

Yayın Yılı

2015

RoHS Durumu

ROHS3 Compliant

Number Of Conductors

ONE

Kurşunsuz

Lead Free

Fabrika Tedarik Süresi

3 Weeks

Montaj Tipi

Through Hole

Seri

SQT

Mil Conformance

NO

Nominal Gerilim

450VAC

Insulation Height

0.250 6.35mm
