Volume pricing
- 1+ pcs$3.46
- 10+ pcs$3.27
- 100+ pcs$3.08
- 500+ pcs$2.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Plating Thickness
- 30μin
- Housing Material
- Polymer
- Row Spacing Mating
- 0.100 (2.54mm)
- Kurşunsuz Kodu
- yes
- Contact Type
- Forked
- ECCN Kodu
- EAR99
- Contact Length Post
- 0.100 2.54mm
- Seri
- SMS
- Orientation
- Straight
- Contact Shape
- Square
- Insulation Height
- 0.335 8.51mm
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Max Current Rating
- 1A
- Pitch Mating
- 0.050 1.27mm
- Fastening Type
- Push-Pull
- Connector Type
- Receptacle
- Contact Finish Mating
- Gold
- Number Of Positions Loaded
- All
- Reference Standard
- UL, CSA
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Contact Resistance
- 10mOhm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- JESD-609 Kodu
- e3
- Current Rating Amps
- 5A per Contact
- Additional Feature
- TIGER BUY CONTACT
- Filter Feature
- NO
- Option
- GENERAL PURPOSE
- Contact Gender
- FEMALE
- Yayın Yılı
- 2014
- Style
- Board to Board
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Phosphor Bronze
- Ambalaj
- Tube
- Depth
- 5.59mm
- Mil Conformance
- NO
- Insulation Color
- Black
- Iec Conformance
- NO
- Number Of Pcb Rows
- 2
