Specifications
- Material Flammability Rating
- UL94 V-0
- Özellikler
- Keying Slot
- Contact Type
- Male Pin
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Sıra Sayısı
- 2
- Housing Material
- Polymer
- Number Of Positions Loaded
- All
- Depth
- 5.59mm
- Reach Svhc
- No SVHC
- Contact Length Post
- 0.075 1.91mm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pozisyon Sayısı
- 34
- JESD-609 Kodu
- e3
- Insulation Color
- Black
- Contact Finish Post
- Tin
- Iec Conformance
- NO
- Contact Finish Mating
- Gold
- Orientation
- Straight
- Shrouding
- Shrouded - 4 Wall
- Connector Type
- Header
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 3 Weeks
- Insulation Height
- 0.210 5.33mm
- Gender
- Male
- Çalışma Sıcaklığı
- -55°C~125°C
- Mil Conformance
- NO
- Uzunluk
- 27.94mm
- Pitch Mating
- 0.050 1.27mm
- Contact Lengthmating
- 0.120 3.05mm
- Option
- GENERAL PURPOSE
- Montaj Tipi
- Through Hole
- Seri
- SHF
- Current Rating Amps
- 3A
- Din Conformance
- NO
- Row Spacing Mating
- 0.050 (1.27mm)
- HTS Kodu
- 8536.69.40.40
- Terminal
- Solder
- Contact Shape
- Square
- Mixed Contacts
- NO
