Volume pricing
- 1+ pcs$5.51
- 10+ pcs$5.20
- 100+ pcs$4.90
- 500+ pcs$4.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Surface Mount
- Connector Type
- Receptacle
- ECCN Kodu
- EAR99
- Filter Feature
- NO
- Row Spacing Mating
- 0.050 (1.27mm)
- Terminal
- Solder
- Voltage Rated Ac
- 350V
- Contact Type
- Female Socket
- HTS Kodu
- 8536.69.40.40
- Total Number Of Contacts
- 30
- Seri
- Tiger Eye™ SFML
- Fastening Type
- Locking Ramp
- Insertion Forcemax
- .556 N
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Parça Durumu
- Active
- Depth
- 3.68mm
- Number Of Conductors
- ONE
- Number Of Positions Loaded
- All
- Contact Resistance
- 15mOhm
- Current Rating Amps
- 3.2A per Contact
- Withdrawl Forcemin
- .417 N
- Max Voltage Rating Ac
- 350V
- Uzunluk
- 22.99mm
- Contact Shape
- Square
- Insulation Height
- 0.185 4.70mm
- Pcb Contact Pattern
- RECTANGULAR
- Insulation Color
- Black
- Pitch Mating
- 0.050 1.27mm
- Contact Materials
- Bronze
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Body Breadth
- 0.095 inch
- Kurşunsuz
- Lead Free
- Sıra Sayısı
- 2
- Number Of Pcb Rows
- 2
- Kurşunsuz Kodu
- yes
- Durability
- 10000 Cycles
- Style
- Board to Board or Cable
- Iec Conformance
- NO
