Volume pricing
- 1+ pcs$3.88
- 10+ pcs$3.66
- 100+ pcs$3.46
- 500+ pcs$3.26
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Radyasyon Dayanımı
- No
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Orientation
- Straight
- Din Conformance
- NO
- Fabrika Tedarik Süresi
- 3 Weeks
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Post
- Tin
- Montaj
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- Style
- Board to Board or Cable
- Iec Conformance
- NO
- Contact Finish Mating
- Gold
- Mil Conformance
- NO
- Pozisyon Sayısı
- 30
- Nominal Gerilim
- 250VAC
- Max Current Rating
- 5A
- Housing Material
- Polymer
- Akım Değeri
- 5A
- RoHS Durumu
- ROHS3 Compliant
- Reach Svhc
- No SVHC
- Sıra Sayısı
- 2
- Kurşunsuz
- Lead Free
- Contact Resistance
- 15mOhm
- Current Rating Amps
- 3.2A per Contact
- Max Voltage Rating Ac
- 350V
- Uzunluk
- 22.99mm
- Insulation Height
- 0.180 4.57mm
- Contact Shape
- Square
- Insulation Color
- Black
- Pitch Mating
- 0.050 1.27mm
- Contact Materials
- Bronze
- Lead Pitch
- 1.27mm
- Depth
- 3.68mm
- Number Of Positions Loaded
- All
- Contact Length Post
- 0.120 3.05mm
