Volume pricing
- 1+ pcs$4.58
- 10+ pcs$4.32
- 100+ pcs$4.07
- 500+ pcs$3.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Filter Feature
- NO
- Connector Type
- Receptacle
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Contact Type
- Female Socket
- Özellikler
- Board Lock
- Sıra Sayısı
- 2
- Terminal
- Solder
- Row Spacing Mating
- 0.050 (1.27mm)
- Seri
- Tiger Eye™ SFML
- Nominal Gerilim
- 250VAC
- Mil Conformance
- NO
- Pozisyon Sayısı
- 20
- Contact Finish Mating
- Gold
- Iec Conformance
- NO
- Style
- Board to Board or Cable
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Fastening Type
- Locking Ramp
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Post
- Tin
- Number Of Positions Loaded
- All
- Fabrika Tedarik Süresi
- 3 Weeks
- Din Conformance
- NO
- Contact Length Post
- 0.120 3.05mm
- Material Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e4
- Montaj
- Through Hole
- Gender
- Female
- Current Rating Amps
- 3.2A per Contact
- Contact Materials
- BERYLLIUM COPPER/PHOSPHOR BRONZE
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Çalışma Sıcaklığı
- -55°C~125°C
- Pitch Mating
- 0.050 1.27mm
- Insulation Color
- Black
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
- Insulation Height
- 0.180 4.57mm
