Volume pricing
- 1+ pcs$12.96
- 10+ pcs$12.22
- 100+ pcs$11.53
- 500+ pcs$10.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Length Post
- 0.120 3.05mm
- Dielectric Withstanding Voltage
- 600VAC V
- Number Of Positions Loaded
- All
- Number Of Conductors
- ONE
- Pitch Mating
- 0.050 1.27mm
- Insulation Color
- Black
- Pcb Contact Pattern
- RECTANGULAR
- Contact Shape
- Square
- Insulation Height
- 0.180 4.57mm
- Contact Materials
- Beryllium Copper
- Current Rating Amps
- 2.9A per Contact
- Contact Resistance
- 10mOhm
- Terminal
- Solder
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Type
- Female Socket
- Connector Type
- Receptacle
- Montaj Tipi
- Through Hole
- Plating Thickness
- 30μin
- Filter Feature
- NO
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Insertion Forcemax
- 1.39 N
- Fastening Type
- Push-Pull
- Parça Durumu
- Active
- Insulation Resistance
- 5000000000Ohm
- Seri
- Tiger Eye™ SFMC
- Montaj
- Through Hole
- Yayın Yılı
- 2014
- Material Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e3
- Din Conformance
- NO
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Post
- Tin
- Fabrika Tedarik Süresi
- 3 Weeks
- Çalışma Sıcaklığı
- -55°C~125°C
- Mating Contact Pitch
- 0.05 inch
- Ambalaj
- Tube
- Polarization Key
- RIGHT
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Radyasyon Dayanımı
- No
