Volume pricing
- 1+ pcs$6.13
- 10+ pcs$5.78
- 100+ pcs$5.46
- 500+ pcs$5.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 3.2A per Contact
- Housing Material
- Polymer
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.185 4.70mm
- Seri
- Tiger Eye™ SFM
- HTS Kodu
- 8536.69.40.40
- Montaj
- Surface Mount
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.050 1.27mm
- Reliability
- COMMERCIAL
- Additional Feature
- TIGER EYE CONTACT
- Number Of Conductors
- ONE
- Housing Color
- Black
- Contact Finish Mating
- Gold
- Contact Materials
- Beryllium Copper
- Sıra Sayısı
- 2
- Özellikler
- Board Lock, Pick and Place
- Gender
- Female
- Max Voltage Rating Ac
- 250V
- Material Flammability Rating
- UL94 V-0
- Plating Thickness
- 30μin
- Connector Type
- Receptacle
- Option
- GENERAL PURPOSE
- Row Spacing Mating
- 0.050 (1.27mm)
- Parça Durumu
- Active
- Fastening Type
- Push-Pull
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Depth
- 3.68mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Type
- Female Socket
- Reference Standard
- UL
- Contact Finish Post
- Tin
- Style
- Board to Board or Cable
- Mil Conformance
- NO
- Montaj Tipi
- Surface Mount
- Pozisyon Sayısı
- 50
- Total Number Of Contacts
- 50
- Stack Height Mating
- 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Yayın Yılı
- 2015
