Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Plating Thickness
- 30μin
- Contact Style
- BELLOWED TYPE
- Mounting Option1
- LOCKING
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Insulator Color
- BLACK
- JESD-609 Kodu
- e3
- Contact Materials
- COPPER ALLOY
- Body Depth
- 0.179 inch
- Seri
- SEARAY™ SEAF
- Ambalaj
- Tape & Reel (TR)
- Polarization Key
- POLARIZED HOUSING
- Contact Finish
- Gold
- Connector Type
- High Density Array, Female
- Operating Temperature Min
- -55°C
- Montaj Tipi
- Surface Mount
- Number Of Pcb Rows
- 8
- Fabrika Tedarik Süresi
- 3 Weeks
- Reliability
- COMMERCIAL
- Stack Height Mating
- 7mm 10mm
- Pitch
- 0.031 0.80mm
- Pozisyon Sayısı
- 240
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Sıra Sayısı
- 8
- Operating Temperature Max
- 125°C
- Özellikler
- Board Guide, Pick and Place
- Rated Current Signal
- 1.4A
- Number Of Conductors
- ONE
- Height Above Board
- 0.180 4.57mm
- Contact Finish Thickness
- 30.0μin 0.76μm
- Pcb Contact Pattern
- RECTANGULAR
- Board Mounting Option
- PEG
- Body Length Or Diameter
- 1.175 inch
- Total Number Of Contacts
- 240
- Contact Pattern
- RECTANGULAR
