Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 5.97mm
- Contact Finish
- Gold
- Total Number Of Contacts
- 180
- Terminal
- Solder
- Iec Conformance
- NO
- Plating Thickness
- 10μin
- Connector Type
- Header, Outer Shroud Contacts
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Ac
- 125V
- Yayın Yılı
- 2015
- Number Of Pcb Rows
- 2
- Radyasyon Dayanımı
- No
- Option
- GENERAL PURPOSE
- Fabrika Tedarik Süresi
- 3 Weeks
- Housing Material
- Polymer
- Additional Feature
- ELP, POLARIZED
- Height Above Board
- 0.954 24.23mm
- RoHS Durumu
- ROHS3 Compliant
- Stack Height Mating
- 25mm
- Pitch
- 0.020 0.50mm
- Din Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Materials
- Bronze
- Pcb Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 2
- Mixed Contacts
- NO
- Reliability
- COMMERCIAL
- Number Of Conductors
- ONE
- Montaj Tipi
- Surface Mount
- Mil Conformance
- NO
- Contact Style
- CENTRONIC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 125°C
- Filter Feature
- NO
- Rated Current Signal
- 2A
- Board Mounting Option
- PEG
- Seri
- Q Strip® QTH
- Insulator Color
- BLACK
- Orientation
- Straight
