Volume pricing
- 1+ pcs$0.19
- 10+ pcs$0.18
- 100+ pcs$0.17
- 500+ pcs$0.16
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Kurşunsuz
- Lead Free
- Connector Type
- Header, Cuttable
- Number Of Conductors
- ONE
- JESD-609 Kodu
- e4
- Shrouding
- Unshrouded
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Contact Lengthmating
- 0.240 6.10mm
- HTS Kodu
- 8536.69.40.40
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- Flex Stack, MTSW
- Iec Conformance
- NO
- Gender
- Male
- Din Conformance
- NO
- Contact Length Post
- 0.090 2.29mm
- Current Rating Amps
- 3A
- Contact Shape
- Square
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -55°C~125°C
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Terminal
- Solder
- Mil Conformance
- NO
- Overall Contact Length
- 0.430 10.92mm
- Contact Finish Mating
- Gold
- Reference Standard
- UL
- Option
- GENERAL PURPOSE
- Insulation Height
- 0.100 2.54mm
- Number Of Pcb Rows
- 1
- Radyasyon Dayanımı
- No
- Reliability
- COMMERCIAL
- Lead Pitch
- 2.54mm
- Contact Type
- Male Pin
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Contact Materials
- Phosphor Bronze
