Volume pricing
- 1+ pcs$3.06
- 10+ pcs$2.88
- 100+ pcs$2.72
- 500+ pcs$2.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Mixed Contacts
- NO
- Pitch Mating
- 0.079 2.00mm
- Iec Conformance
- NO
- Contact Shape
- Square
- Çalışma Sıcaklığı
- -55°C~125°C
- Uzunluk
- 16mm
- Option
- GENERAL PURPOSE
- Orientation
- Right Angle
- Material Flammability Rating
- UL94 V-0
- Insulation Height
- 0.157 4.00mm
- Number Of Positions Loaded
- All
- Parça Durumu
- Active
- JESD-609 Kodu
- e3
- Yayın Yılı
- 2016
- Montaj Tipi
- Surface Mount, Right Angle
- Mil Conformance
- NO
- Insulation Color
- Black
- Din Conformance
- NO
- Depth
- 10.35mm
- Sıra Sayısı
- 2
- Row Spacing Mating
- 0.079 (2.00mm)
- Total Number Of Contacts
- 16
- Özellikler
- Pick and Place
- Fastening Type
- Push-Pull
- Contact Lengthmating
- 0.126 3.20mm
- Terminal
- Solder
- Contact Type
- Male Pin
- Pozisyon Sayısı
- 16
- Radyasyon Dayanımı
- No
- Connector Type
- Header
- Housing Material
- Polymer
- Gender
- Male
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- RoHS Durumu
- ROHS3 Compliant
- Style
- Board to Board or Cable
- Contact Finish Post
- Tin
- HTS Kodu
- 8536.69.40.40
- Fabrika Tedarik Süresi
- 3 Weeks
- Filter Feature
- NO
