Volume pricing
- 1+ pcs$4.75
- 10+ pcs$4.48
- 100+ pcs$4.22
- 500+ pcs$3.98
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Filter Feature
- NO
- Uzunluk
- 26.92mm
- Contact Type
- Male Pin
- Gender
- Male
- Contact Materials
- Phosphor Bronze
- Fastening Type
- Locking Ramp
- Number Of Positions Loaded
- All
- Row Spacing Mating
- 0.100 (2.54mm)
- Nominal Gerilim
- 675VAC 954VDC
- Option
- GENERAL PURPOSE
- Max Current Rating
- 7.4A
- Ambalaj
- Tube
- Montaj Tipi
- Through Hole
- Sıra Sayısı
- 2
- Body Depth
- 0.345 inch
- Parça Durumu
- Active
- Shrouding
- Shrouded - 4 Wall
- Orientation
- Straight
- Contact Finish Mating
- Gold
- Insulation Color
- Natural
- JESD-609 Kodu
- e3
- Kurşunsuz Kodu
- yes
- Reliability
- COMMERCIAL
- Style
- Board to Cable/Wire
- Terminal
- Solder
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Çalışma Sıcaklığı
- -55°C~125°C
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Body Breadth
- 0.357 inch
- HTS Kodu
- 8536.69.40.30
- Material Flammability Rating
- UL94 V-0
- Mixed Contacts
- NO
- Radyasyon Dayanımı
- No
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Insulation Height
- 0.320 8.13mm
- RoHS Durumu
- ROHS3 Compliant
- Reference Standard
- UL
- Max Voltage Rating Ac
- 675V
- Yayın Yılı
- 2013
