Volume pricing
- 1+ pcs$2.86
- 10+ pcs$2.69
- 100+ pcs$2.54
- 500+ pcs$2.40
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Radyasyon Dayanımı
- No
- Contact Materials
- Phosphor Bronze
- Gender
- Male
- Contact Type
- Male Pin
- Mixed Contacts
- NO
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Terminal
- Solder
- Filter Feature
- NO
- Pozisyon Sayısı
- 4
- Yayın Yılı
- 2013
- Nominal Gerilim
- 675VAC 954VDC
- Özellikler
- Board Guide
- Option
- GENERAL PURPOSE
- Number Of Positions Loaded
- All
- RoHS Durumu
- ROHS3 Compliant
- Fastening Type
- Locking Ramp
- Insulation Height
- 0.220 5.60mm
- Total Number Of Contacts
- 4
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pitch Mating
- 0.100 2.54mm
- Din Conformance
- NO
- Parça Durumu
- Active
- Shrouding
- Shrouded - 4 Wall
- Orientation
- Right Angle
- Sıra Sayısı
- 1
- Connector Type
- Header
- Mil Conformance
- NO
- Montaj Tipi
- Surface Mount, Right Angle
- Fabrika Tedarik Süresi
- 3 Weeks
- Contact Lengthmating
- 0.215 5.46mm
- Contact Finish Post
- Tin
- Ambalaj
- Tape & Reel (TR)
- Iec Conformance
- NO
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Seri
- Mini Mate® IPL1
- Additional Feature
- POLARIZED
