Volume pricing
- 1+ pcs$1.74
- 10+ pcs$1.64
- 100+ pcs$1.55
- 500+ pcs$1.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Dielectric Withstanding Voltage
- 1400VAC V
- Yayın Yılı
- 2011
- Özellikler
- Open Frame
- Number Of Contacts
- 8
- RoHS Durumu
- ROHS3 Compliant
- Depth
- 10.03mm
- Termination Post Length
- 0.125 3.18mm
- Insulation Materials
- Polyester
- Contact Materials
- Copper
- Gender
- Female
- Contact Resistance
- 10mOhm
- Uzunluk
- 10.16mm
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Body Breadth
- 0.395 inch
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Pattern
- RECTANGULAR
- Tip
- DIP, 0.3 (7.62mm) Row Spacing
- Contact Material Post
- Brass
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Terminal
- Solder
- Number Of Positions Or Pins Grid
- 8 (2 x 4)
- Lead Length
- 3.175mm
- Insulation Resistance
- 5GOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- ICA
- Mating Contact Pitch
- 0.1 inch
- Flammability Rating
- UL94 V-0
- Additional Feature
- STANDARD: UL 94V-0
- JESD-609 Kodu
- e3
- Kurşunsuz Kodu
- yes
- Contact Finish Mating
- Gold
- Contact Material Mating
- Beryllium Copper
- Pitch Mating
- 0.100 2.54mm
- Contact Style
- MACHINE SCREW
- Contact Finish Thickness Post
- 10.0μin 0.25μm
- Pitch Post
- 0.100 2.54mm
- REACH Uyumluluk Kodu
- not_compliant
- Parça Durumu
- Active
