Volume pricing
- 1+ pcs$2.78
- 10+ pcs$2.63
- 100+ pcs$2.48
- 500+ pcs$2.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Phosphor Bronze
- Insulation Height
- 0.100 2.54mm
- Number Of Positions Loaded
- All
- Montaj
- Through Hole
- Current Rating Amps
- Varies by WireGAuge
- Filter Feature
- NO
- Style
- Board to Board or Cable
- Ul Flammability Code
- 94V-0
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Mil Conformance
- NO
- HTS Kodu
- 8536.69.40.40
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 1
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- JESD-609 Kodu
- e4
- Iec Conformance
- NO
- Seri
- HTSW
- Yayın Yılı
- 2005
- Pitch Mating
- 0.100 2.54mm
- Pcb Contact Pattern
- RECTANGULAR
- Din Conformance
- NO
- Connector Type
- Header
- Contact Finish Mating
- Gold
- Çalışma Sıcaklığı
- -55°C~125°C
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 3 Weeks
- Pozisyon Sayısı
- 22
- Insulation Color
- Natural
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal
- Solder
- Ambalaj
- Bulk
- Lead Pitch
- 2.54mm
- Option
- GENERAL PURPOSE
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Overall Contact Length
- 0.300 7.62mm
- Contact Lengthmating
- 0.105 2.67mm
- Number Of Conductors
- ONE
