Specifications
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 2
- HTS Kodu
- 8536.69.40.40
- Mil Conformance
- NO
- Current Rating Amps
- Varies by WireGAuge
- Filter Feature
- NO
- Mating Contact Pitch
- 0.1 inch
- Style
- Board to Board or Cable
- Plating Thickness
- 30μin
- Number Of Positions Loaded
- All
- Reference Standard
- UL
- Insulation Height
- 0.100 2.54mm
- Additional Feature
- E.L.P.
- Contact Materials
- Phosphor Bronze
- Pitch Mating
- 0.100 2.54mm
- Seri
- HTSW
- Yayın Yılı
- 2011
- Kurşunsuz Kodu
- yes
- JESD-609 Kodu
- e3
- Iec Conformance
- NO
- Max Current Rating
- 7.6A
- Fastening Type
- Push-Pull
- Contact Shape
- Square
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Option
- GENERAL PURPOSE
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- Ambalaj
- Bulk
- Insulation Color
- Natural
- Material Flammability Rating
- UL94 V-0
- Çalışma Sıcaklığı
- -55°C~125°C
- Parça Durumu
- Active
- Pozisyon Sayısı
- 20
- Housing Material
- Polymer
- Fabrika Tedarik Süresi
- 3 Weeks
- Max Voltage Rating Ac
- 550V
- Contact Finish Mating
- Gold
- Row Spacing Mating
- 0.100 (2.54mm)
- Connector Type
- Header
