HTSW-105-07-F-T

Specifications

Body Length Or Diameter

0.5 inch

Contact Type

Male Pin

Contact Length Post

0.100 2.54mm

Radyasyon Dayanımı

No

ECCN Kodu

EAR99

Contact Finish Post

Tin

RoHS Durumu

ROHS3 Compliant

Gender

Male

Overall Contact Length

0.430 10.92mm

Contact Lengthmating

0.230 5.84mm

Number Of Conductors

ONE

Shrouding

Unshrouded

Body Breadth

0.298 inch

Reach Svhc

No SVHC

Mixed Contacts

NO

Montaj Tipi

Through Hole

Sıra Sayısı

3

Terminal

Solder

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ambalaj

Bulk

Lead Pitch

2.54mm

Option

GENERAL PURPOSE

Insulation Materials

Liquid Crystal Polymer (LCP)

Contact Finish Thickness Mating

3.00μin 0.076μm

Pcb Contact Pattern

RECTANGULAR

Din Conformance

NO

Contact Finish Mating

Gold

Row Spacing Mating

0.100 (2.54mm)

Connector Type

Header

Material Flammability Rating

UL94 V-0

Parça Durumu

Active

Çalışma Sıcaklığı

-55°C~125°C

Pozisyon Sayısı

15

Fabrika Tedarik Süresi

3 Weeks

Insulation Color

Natural

Seri

HTSW

Yayın Yılı

2005

Pitch Mating

0.100 2.54mm

Contact Shape

Square

Fastening Type

Push-Pull
