Specifications
- Number Of Pcb Rows
- 1
- Reliability
- COMMERCIAL
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Mil Conformance
- NO
- Number Of Positions Loaded
- All
- Style
- Board to Board or Cable
- Filter Feature
- NO
- Current Rating Amps
- Varies by WireGAuge
- Contact Materials
- Phosphor Bronze
- Additional Feature
- E.L.P.
- Insulation Height
- 0.100 2.54mm
- Pitch Mating
- 0.100 2.54mm
- Yayın Yılı
- 2005
- Kurşunsuz Kodu
- yes
- Seri
- HTSW
- Max Current Rating
- 7.6A
- JESD-609 Kodu
- e4
- Iec Conformance
- NO
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Option
- GENERAL PURPOSE
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Ambalaj
- Bulk
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- Not Applicable
- Lead Pitch
- 2.54mm
- Pozisyon Sayısı
- 3
- Fabrika Tedarik Süresi
- 3 Weeks
- Housing Material
- Polymer
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~125°C
- Insulation Color
- Natural
- Din Conformance
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Header
- Contact Finish Mating
- Gold
- Max Voltage Rating Ac
- 550V
