Volume pricing
- 1+ pcs$0.27
- 10+ pcs$0.26
- 100+ pcs$0.24
- 500+ pcs$0.23
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Lengthmating
- 0.230 5.84mm
- Overall Contact Length
- 0.430 10.92mm
- Depth
- 2.48mm
- Body Breadth
- 0.098 inch
- Shrouding
- Unshrouded
- Number Of Conductors
- ONE
- Uzunluk
- 7.62mm
- Sıra Sayısı
- 1
- Montaj Tipi
- Through Hole
- Mixed Contacts
- NO
- Contact Type
- Male Pin
- Orientation
- Straight
- Contact Length Post
- 0.100 2.54mm
- Radyasyon Dayanımı
- No
- Gender
- Male
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Post
- Tin
- Din Conformance
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Mating
- Gold
- Connector Type
- Header
- Max Voltage Rating Ac
- 550V
- Fabrika Tedarik Süresi
- 6 Weeks
- Housing Material
- Polymer
- Pozisyon Sayısı
- 3
- Çalışma Sıcaklığı
- -55°C~125°C
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Housing Color
- Natural
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Option
- GENERAL PURPOSE
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Terminal Adımı
- 2.54mm
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Max Current Rating
- 7.6A
- JESD-609 Kodu
- e3
