Specifications
- Contact Length Post
- 0.130 3.30mm
- Gender
- Male
- RoHS Durumu
- ROHS3 Compliant
- Iec Conformance
- NO
- Pitch Mating
- 0.100 2.54mm
- Number Of Pcb Rows
- 1
- Parça Durumu
- Active
- Uzunluk
- 5.08mm
- JESD-609 Kodu
- e3
- Reliability
- COMMERCIAL
- Max Current Rating
- 7.6A
- Seri
- HTSW
- Fabrika Tedarik Süresi
- 3 Weeks
- Shrouding
- Unshrouded
- Housing Material
- Polymer
- Insulation Height
- 0.100 2.54mm
- Connector Type
- Header
- Contact Shape
- Square
- Lead Pitch
- 2.54mm
- Radyasyon Dayanımı
- No
- Fastening Type
- Push-Pull
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Yayın Yılı
- 2005
- Current Rating Amps
- Varies by WireGAuge
- Additional Feature
- E.L.P.
- Contact Finish Post
- Tin
- Overall Contact Length
- 0.335 8.51mm
- Mil Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Lengthmating
- 0.105 2.67mm
- Filter Feature
- NO
- Pozisyon Sayısı
- 2
- Sıra Sayısı
- 1
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~125°C
- Number Of Conductors
- ONE
- Terminal
- Solder
- Number Of Positions Loaded
- All
