Volume pricing
- 1+ pcs$2.90
- 10+ pcs$2.74
- 100+ pcs$2.58
- 500+ pcs$2.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Mating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tube
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Contact Materials
- Phosphor Bronze
- Option
- GENERAL PURPOSE
- Montaj Tipi
- Through Hole, Right Angle
- Style
- Board to Cable/Wire
- Contact Type
- Male Pin
- Depth
- 12.32mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Özellikler
- Keying Slot
- Sıra Sayısı
- 2
- Din Conformance
- NO
- Number Of Conductors
- ONE
- Number Of Positions Loaded
- All
- Terminal
- Solder
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Lengthmating
- 0.250 6.35mm
- Material Flammability Rating
- UL94 V-0
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Filter Feature
- NO
- Pozisyon Sayısı
- 10
- Mil Conformance
- NO
- Row Spacing Mating
- 0.100 (2.54mm)
- Current Rating Amps
- 3.4A per Contact
- Yayın Yılı
- 2013
- Housing Color
- Natural
- Fastening Type
- Push-Pull
- Orientation
- Right Angle
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Contact Shape
- Square
- Connector Type
- Header
- Insulation Height
- 0.365 9.27mm
- Fabrika Tedarik Süresi
- 3 Weeks
