Volume pricing
- 1+ pcs$3.37
- 10+ pcs$3.18
- 100+ pcs$3.00
- 500+ pcs$2.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mil Conformance
- NO
- Option
- GENERAL PURPOSE
- Number Of Positions Loaded
- All
- Insulation Height
- 0.144 3.66mm
- Terminal
- Solder
- Additional Feature
- TIGER BEAM CONTACT
- Contact Finish Mating
- Gold
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Insulation Color
- Black
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Özellikler
- Pick and Place
- Radyasyon Dayanımı
- No
- Connector Type
- Receptacle
- Contact Materials
- Beryllium Copper
- Orientation
- Straight
- Contact Finish Post
- Tin
- Ambalaj
- Tape & Reel (TR)
- HTS Kodu
- 8536.69.40.40
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Female
- Iec Conformance
- NO
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 3 Weeks
- Current Rating Amps
- 4.1A per Contact
- ECCN Kodu
- EAR99
- Depth
- 5.08mm
- Max Current Rating
- 2.5A
- Row Spacing Mating
- 0.100 (2.54mm)
- Style
- Board to Board
- Total Number Of Contacts
- 18
- Din Conformance
- NO
- Uzunluk
- 22.86mm
- Pitch Mating
- 0.100 2.54mm
- Contact Shape
- Square
- Pozisyon Sayısı
- 18
- Seri
- HLE
- Housing Material
- Polymer
- Mixed Contacts
- NO
- Max Voltage Rating Ac
- 400V
