Volume pricing
- 1+ pcs$4.82
- 10+ pcs$4.54
- 100+ pcs$4.29
- 500+ pcs$4.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Tape & Reel (TR)
- HTS Kodu
- 8536.69.40.40
- Terminal
- Solder
- Contact Finish Post
- Tin
- Seri
- FTSH
- Montaj Tipi
- Surface Mount
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Mating Contact Pitch
- 0.05 inch
- Number Of Pcb Rows
- 2
- Connector Type
- Header, Cuttable
- Plating Thickness
- 10μin
- Mounting Option1
- LOCKING
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Contact Finish Mating
- Gold
- Reach Svhc
- No SVHC
- Contact Shape
- Square
- Filter Feature
- NO
- Pozisyon Sayısı
- 50
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Sıra Sayısı
- 2
- Number Of Conductors
- ONE
- Contact Type
- Male Pin
- Orientation
- Straight
- Özellikler
- Keying Shroud
- Çalışma Sıcaklığı
- -55°C~125°C
- Housing Material
- Polymer
- Contact Materials
- Phosphor Bronze
- JESD-609 Kodu
- e3
- Current Rating Amps
- 3.4A per Contact
- Mil Conformance
- NO
- Body Breadth
- 0.135 inch
- Fabrika Tedarik Süresi
- 4 Weeks
- Depth
- 5.84mm
- Number Of Positions Loaded
- All
- Shrouding
- Unshrouded
- Uzunluk
- 31.75mm
- Contact Lengthmating
- 0.120 3.05mm
- Reference Standard
- UL
