Volume pricing
- 1+ pcs$5.47
- 10+ pcs$5.16
- 100+ pcs$4.86
- 500+ pcs$4.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Surface Mount
- Number Of Pcb Rows
- 2
- Mating Contact Pitch
- 0.05 inch
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Connector Type
- Header, Cuttable
- Montaj
- Surface Mount
- Ambalaj
- Tape & Reel (TR)
- Seri
- FTSH
- Contact Finish Post
- Tin
- Terminal
- Solder
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Mating
- Gold
- Plating Thickness
- 10μin
- Filter Feature
- NO
- Contact Shape
- Square
- Number Of Conductors
- ONE
- Contact Type
- Male Pin
- Orientation
- Straight
- Özellikler
- End Shrouds, Pick and Place
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pozisyon Sayısı
- 40
- Sıra Sayısı
- 2
- Mil Conformance
- NO
- Fabrika Tedarik Süresi
- 6 Weeks
- Body Breadth
- 0.135 inch
- Shrouding
- Unshrouded
- Number Of Positions Loaded
- All
- Depth
- 5.84mm
- Çalışma Sıcaklığı
- -55°C~125°C
- JESD-609 Kodu
- e3
- Contact Materials
- Phosphor Bronze
- Housing Material
- Polymer
- Current Rating Amps
- 3.4A per Contact
- Insulation Height
- 0.099 2.51mm
- Mixed Contacts
- NO
- Uzunluk
- 41.17mm
- Contact Lengthmating
- 0.120 3.05mm
- Reference Standard
- UL
