Specifications
- Contact Lengthmating
- 0.120 3.05mm
- Current Rating Amps
- 3.4A per Contact
- Style
- Board to Board or Cable
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Seri
- FTSH
- RoHS Durumu
- ROHS3 Compliant
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 10
- Terminal
- Solder
- Insulation Color
- Black
- Ambalaj
- Tape & Reel (TR)
- Montaj Tipi
- Surface Mount
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- 9
- Shrouding
- Unshrouded
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Fabrika Tedarik Süresi
- 4 Weeks
- Connector Type
- Header, Cuttable
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 3.00μin 0.076μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Row Spacing Mating
- 0.050 (1.27mm)
- Pitch Mating
- 0.050 1.27mm
- Insulation Height
- 0.099 2.51mm
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Özellikler
- Pick and Place
- Contact Finish Mating
- Gold
- Contact Type
- Male Pin
- JESD-609 Kodu
- e3
- Contact Finish Post
- Tin
