Volume pricing
- 1+ pcs$1.25
- 10+ pcs$1.18
- 100+ pcs$1.11
- 500+ pcs$1.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gender
- Male
- Pcb Contact Pattern
- RECTANGULAR
- Housing Material
- Polymer
- Uzunluk
- 6.35mm
- Row Spacing Mating
- 0.050 (1.27mm)
- Contact Shape
- Square
- Contact Finish Mating
- Gold
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Yayın Yılı
- 2008
- Contact Length Post
- 0.090 2.29mm
- Reliability
- COMMERCIAL
- Plating Thickness
- 3μin
- RoHS Durumu
- ROHS3 Compliant
- Option
- GENERAL PURPOSE
- Max Current Rating
- 1.75A
- Depth
- 3.43mm
- Kurşunsuz Kodu
- yes
- Contact Lengthmating
- 0.120 3.05mm
- Current Rating Amps
- 3.4A per Contact
- Style
- Board to Board or Cable
- Additional Feature
- ELP
- HTS Kodu
- 8536.69.40.40
- Shrouding
- Unshrouded
- Din Conformance
- NO
- Insulation Color
- Black
- Terminal
- Solder
- Contact Materials
- Phosphor Bronze
- Fabrika Tedarik Süresi
- 1 Weeks
- Mating Contact Pitch
- 0.05 inch
- Insulation Height
- 0.099 2.51mm
- Body Breadth
- 0.135 inch
- Filter Feature
- NO
- Pitch Mating
- 0.050 1.27mm
- Orientation
- Straight
- Fastening Type
- Push-Pull
- Iec Conformance
- NO
- JESD-609 Kodu
- e3
- ECCN Kodu
- EAR99
- Number Of Conductors
- ONE
