Volume pricing
- 1+ pcs$2.08
- 10+ pcs$1.96
- 100+ pcs$1.85
- 500+ pcs$1.74
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Overall Contact Length
- 0.244 6.20mm
- Parça Durumu
- Active
- Seri
- FTS
- Current Rating Amps
- 3.4A per Contact
- Mixed Contacts
- NO
- Style
- Board to Board or Cable
- Contact Lengthmating
- 0.120 3.05mm
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- RoHS Durumu
- ROHS3 Compliant
- Material Flammability Rating
- UL94 V-0
- Pozisyon Sayısı
- 17
- Sıra Sayısı
- 1
- Insulation Color
- Black
- Terminal
- Solder
- Ambalaj
- Tube
- Montaj Tipi
- Through Hole
- Contact Materials
- Phosphor Bronze
- Additional Feature
- LOW PROFILE
- Ul Flammability Code
- 94V-0
- Din Conformance
- NO
- Shrouding
- Unshrouded
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Montaj
- Through Hole
- Number Of Positions Loaded
- All
- Gender
- Male
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 3 Weeks
- Yayın Yılı
- 2012
- Connector Type
- Header, Cuttable
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness Mating
- 3.00μin 0.076μm
- Contact Length Post
- 0.090 2.29mm
- Mil Conformance
- NO
- Contact Shape
- Square
- Pitch Mating
- 0.050 1.27mm
- Insulation Height
- 0.034 0.86mm
- Filter Feature
- NO
- Contact Type
- Male Pin
