Volume pricing
- 1+ pcs$4.14
- 10+ pcs$3.90
- 100+ pcs$3.68
- 500+ pcs$3.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Din Conformance
- NO
- Fabrika Tedarik Süresi
- 3 Weeks
- Contact Resistance
- 10mOhm
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Contact Length Post
- 0.090 2.29mm
- Radyasyon Dayanımı
- No
- Current Rating Amps
- 5.2A per Contact
- Contact Shape
- Square
- Pozisyon Sayısı
- 26
- RoHS Durumu
- ROHS3 Compliant
- Style
- Board to Board
- Montaj
- Through Hole
- Insertion Forcemax
- 1.668 N
- Ambalaj
- Tube
- Insulation Height
- 0.435 11.05mm
- Contact Finish Post
- Tin
- Sıra Sayısı
- 2
- Contact Type
- Forked
- Connector Type
- Elevated Socket
- Number Of Pcb Rows
- 2
- Yayın Yılı
- 2010
- Pitch Mating
- 0.100 2.54mm
- Filter Feature
- NO
- Withdrawl Forcemin
- 1.39 N
- Gender
- Receptacle
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
- Contact Materials
- Phosphor Bronze
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Max Current Rating
- 3A
- Fastening Type
- Push-Pull
- Parça Durumu
- Active
- Nominal Gerilim
- 550VAC
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pcb Contact Pattern
- RECTANGULAR
- Çalışma Sıcaklığı
- -55°C~125°C
- Reference Standard
- UL, CSA
- Seri
- ESW
